LARGUS SPEC S IMPORT COILOVER KIT FOR ALFAROMEO 147 937AXL 2WD 01011221001-QQ-1363
| Brand | LARGUS |
| Series Name | SPEC S IMPORT COILOVER KIT |
| Product Number | 01011221001-QQ-1363 |
| Compatible Car | ALFAROMEO 147 937AXL 2WD |
| Product Description | Car Manufacturer: Alfa Romeo Model: 147 Vehicle Model: 937AXL Year: 2003.5~ Drive System: 2WD Product: Full-Length Adjustable Coilover Kit SpecS Import Spring Rate F: 10kg Spring Rate R: 3kg Free Length F: 200mm Free Length R: 250mm Upper Mount F: Fixed Reinforced Rubber Upper Mount R: Fixed Reinforced Rubber F Damping Position: Separate Dial (Upper Mount) R Damping Position R: Fixed Dial (Upper Mount) Vehicle Height Adjustment Range F (Reference Value): 602mm - 682mm Vehicle Height Adjustment Range R (Reference Value): 595mm to 695mm Down amount F (reference value): -56mm to +24mm Down amount R (reference value): -97mm to +3mm |
| Remarks | The rear upper mount is not a standard reinforced rubber upper, but a special type that is clamped from the top of the body with a rigid mount. *The vehicle height setting range, lowering amount, and installation images are reference values based on the development vehicle. There may be discrepancies due to individual vehicle differences and assembly conditions. *For vehicles with adaptive shock absorbers (electronically controlled dampers, etc.), a warning light will come on, so a separate canceller or other countermeasure will be required. *The specifications and accessories of this product are subject to change without notice for improvement purposes. CAN ONLY BE SHIPPED WITH UPS OR FEDEX |
| Notes | Images are for illustration purpose only. Actual product may vary. |
| Brand | LARGUS |
| Series Name | SPEC S IMPORT COILOVER KIT |
| Product Number | 01011221001-QQ-1363 |
| Compatible Car | ALFAROMEO 147 937AXL 2WD |
| Product Description | Car Manufacturer: Alfa Romeo Model: 147 Vehicle Model: 937AXL Year: 2003.5~ Drive System: 2WD Product: Full-Length Adjustable Coilover Kit SpecS Import Spring Rate F: 10kg Spring Rate R: 3kg Free Length F: 200mm Free Length R: 250mm Upper Mount F: Fixed Reinforced Rubber Upper Mount R: Fixed Reinforced Rubber F Damping Position: Separate Dial (Upper Mount) R Damping Position R: Fixed Dial (Upper Mount) Vehicle Height Adjustment Range F (Reference Value): 602mm - 682mm Vehicle Height Adjustment Range R (Reference Value): 595mm to 695mm Down amount F (reference value): -56mm to +24mm Down amount R (reference value): -97mm to +3mm |
| Remarks | The rear upper mount is not a standard reinforced rubber upper, but a special type that is clamped from the top of the body with a rigid mount. *The vehicle height setting range, lowering amount, and installation images are reference values based on the development vehicle. There may be discrepancies due to individual vehicle differences and assembly conditions. *For vehicles with adaptive shock absorbers (electronically controlled dampers, etc.), a warning light will come on, so a separate canceller or other countermeasure will be required. *The specifications and accessories of this product are subject to change without notice for improvement purposes. CAN ONLY BE SHIPPED WITH UPS OR FEDEX |
| Notes | Images are for illustration purpose only. Actual product may vary. |
